SN74HCT245DGSR TI Bus Transceiver | 20-VSSOP | 8-Bit, Non-Inverting, 3-State

Product Overview

The SN74HCT245DGSR is a high-performance octal bus transceiver from Texas Instruments, designed for asynchronous bidirectional communication between data buses. It features 8-bit non-inverting buffers with 3-state outputs, enabling efficient data flow control in mixed-voltage systems. Housed in a compact 20-VSSOP package, this device operates over a wide supply voltage range of 4.5V to 5.5V, making it ideal for 5V logic environments. With TTL-compatible inputs and CMOS outputs, it bridges legacy and modern logic families seamlessly.

Detailed Technical Specifications

Key Features

• Bidirectional bus transceiver with 8-bit non-inverting data paths
• 3-state outputs for bus-oriented applications
• TTL input compatibility with CMOS output levels
• Low power consumption: ICC max 80 µA
• High noise immunity: VNH min 0.7V at 5V
• ESD protection exceeds 2000V per MIL-STD-883
• Available in lead-free and RoHS-compliant package

Target Applications

• 5G base station control boards for data routing between processors and FPGAs
• Automotive dashboard display modules for signal buffering between MCU and LCD driver
• Industrial PLC I/O modules for isolating and driving relay outputs
• Telecommunications line cards for backplane bus interfacing
• Medical imaging equipment for data acquisition system bus management

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74HCT245DGSR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
