SN74LS248N TI BCD-to-7-Segment Decoder/Driver | 4-Bit Input, Open-Collector Output

Product Overview

The SN74LS248N is a BCD-to-7-segment decoder/driver from Texas Instruments, designed to convert 4-bit binary-coded decimal (BCD) input into signals for driving 7-segment displays. It features open-collector outputs capable of sinking up to 24 mA, making it suitable for driving common-anode LED displays. The device includes a lamp test input and a blanking input for display control.

Detailed Technical Specifications

Key Features

• BCD to 7-segment decoding
• Open-collector outputs for direct LED drive
• Lamp test and blanking inputs
• Active low outputs for common-anode displays
• Schmitt-triggered inputs for noise immunity

Target Applications

• Digital voltmeters and multimeters
• Industrial panel meters
• Automotive dashboard displays
• 5G base station status indicators
• Medical equipment numeric displays
