SN74LV4053ANS TI Analog Switch IC | Triple SPDT | 2V-5.5V, 75Ohm

Product Overview

The SN74LV4053ANS is a triple single-pole double-throw (SPDT) analog switch from Texas Instruments, designed for general-purpose switching applications. It operates over a wide supply voltage range of 2V to 5.5V, making it suitable for battery-powered and low-voltage systems. Each switch features low on-state resistance (75Ω typical) and high off-state isolation, ensuring minimal signal distortion. The device is available in a 16-pin SO package (NS suffix) and is characterized for operation from -40°C to +85°C.

Detailed Technical Specifications

Key Features

• Triple SPDT switch configuration
• Wide supply voltage range: 2V to 5.5V
• Low on-state resistance: 75Ω typical
• High bandwidth: 50 MHz
• Fast switching speeds: 14ns typical
• Low power consumption: 1μA max
• Break-before-make switching
• ESD protection: 2000V HBM

Target Applications

• Audio and video signal routing in consumer electronics (e.g., smart TVs, set-top boxes)
• Analog multiplexing in industrial control systems (e.g., PLCs, data acquisition)
• Signal switching in communication infrastructure (e.g., 5G base stations, routers)
• Battery-powered portable devices (e.g., smartphones, tablets)
• Automotive infotainment and dashboard systems

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LV4053ANS. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
