SN74LVC2G00DCTR TI Logic Gates | SM8 | 1.65V-5.5V, 2-Input NAND

Product Overview

The SN74LVC2G00DCTR is a dual 2-input NAND gate from Texas Instruments, designed for 1.65-V to 5.5-V VCC operation. This device performs the Boolean function Y = A ● B or Y = A + B in positive logic. It is fabricated with advanced LVC technology to achieve high speed and low power consumption. The SN74LVC2G00DCTR is available in the SM8 package (SOT-23-8), making it suitable for space-constrained applications.

Detailed Technical Specifications

Key Features

• Wide operating voltage range: 1.65 V to 5.5 V
• High drive capability: ±32 mA at 3 V
• Low power consumption: 10 µA max ICC
• High speed: tpd = 3.8 ns typ at 3.3 V
• Inputs accept voltages up to 5.5 V
• Supports down translation to VCC
• ESD protection exceeds JESD 22: 2000-V Human-Body Model (A114-A)
• Latch-up performance exceeds 100 mA per JESD 78, Class II
• Available in SM8 (SOT-23-8) package

Target Applications

• 5G base station control logic: Used for signal gating and decoding in baseband processing units.
• Automotive dashboard: Implements logic functions for display control and sensor interface.
• Industrial automation: Logic gating in PLCs and motor control units.
• Consumer electronics: Power management and interface logic in smartphones and tablets.
• Networking equipment: Signal routing in switches and routers.

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LVC2G00DCTR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

SN74LVC2G00DCTR 是德州儀器推出的雙路2輸入與非門，支持1.65V至5.5V的電源電壓範圍。該器件採用先進的LVC技術，實現高速和低功耗。邏輯功能為 Y = A ● B 或 Y = A + B（正邏輯）。封裝為SM8（SOT-23-8），適合空間受限的應用。

詳細技術參數

核心特性

• 寬電源電壓範圍：1.65 V 至 5.5 V
• 高驅動能力：3V時±32 mA
• 低功耗：最大ICC 10 µA
• 高速：3.3V時典型傳播延遲3.8 ns
• 輸入可承受5.5V電壓
• 支持向下轉換至VCC
• ESD保護超過JESD 22標準：2000-V人體模型（A114-A）
• 閂鎖性能超過100 mA（JESD 78, Class II）
• 封裝：SM8（SOT-23-8）

典型應用場景

• 5G基站控制邏輯：用於基帶處理單元中的信號選通和解碼。
• 汽車儀表盤：實現顯示控制和傳感器接口的邏輯功能。
• 工業自動化：PLC和電機控制單元中的邏輯門控。
• 消費電子：智能手機和平板電腦中的電源管理和接口邏輯。
• 網絡設備：交換機和路由器中的信號路由。

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 SN74LVC2G00DCTR 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
