SN74LVC2T45DCTR TI Dual-Bit Voltage-Level Translator | SM8 | 1.65-5.5V, 500Mbps

Product Overview

The SN74LVC2T45DCTR is a dual-bit non-inverting bus transceiver from Texas Instruments, designed for asynchronous communication between two voltage nodes. It features two independent supply voltages (VCCA and VCCB), each operating from 1.65 V to 5.5 V, enabling bidirectional level translation for a wide range of logic levels. The device supports data rates up to 500 Mbps, making it suitable for high-speed signal translation in mixed-voltage systems. Housed in the compact SM8 (DCT) package, it is ideal for space-constrained applications.

Detailed Technical Specifications

Key Features

• Bidirectional voltage-level translation for 2 bits
• Wide supply range: 1.65 V to 5.5 V on both ports
• High data rate: up to 500 Mbps
• Low power consumption: ICC max 10 µA
• Ioff partial-power-down mode disables outputs, preventing backflow current
• Latch-up performance exceeds 100 mA per JESD 78, Class II
• Available in small SM8 package for space-saving designs

Target Applications

• 5G base station control boards: translating between 1.8V MCU and 3.3V FPGA I/Os
• Automotive dashboard displays: interfacing 1.8V sensor data to 3.3V display controller
• Industrial PLC modules: level shifting for 24V to 3.3V logic signals
• Consumer electronics: smartphone accessory communication (e.g., 1.8V to 3.3V UART)
• Networking equipment: translating between 2.5V and 3.3V Ethernet PHY interfaces
