TPS61305YFFT TI LED Driver | 20-DSBGA | 2.5V-5.5V, 1.5A

Product Overview

The TPS61305YFFT from Texas Instruments is a high-efficiency, synchronous boost converter with an integrated 1.5A switch, designed to drive up to 10 series white LEDs. It operates from a single Li-Ion cell or standard 3.3V/5V rails, delivering up to 38V output. The device features a 2.5V to 5.5V input range and a fixed 1.2MHz switching frequency, enabling small external components. The TPS61305YFFT is available in a compact 20-pin DSBGA package (2.0mm x 1.5mm).

Detailed Technical Specifications

Key Features

• Integrated 1.5A switch with overcurrent protection
• True shutdown isolation (output disconnected from input)
• PWM dimming control via EN pin
• Overvoltage protection (OVP) at 38V
• Thermal shutdown
• Small solution size with minimal external components

Target Applications

• Smartphone and tablet display backlighting (e.g., iPhone 14, Samsung Galaxy S23)
• Automotive dashboard and infotainment displays (e.g., Tesla Model 3 center display)
• 5G base station indicator LEDs (e.g., Huawei 5G AAU)
• Portable medical devices (e.g., finger pulse oximeter displays)
• Industrial control panel backlighting

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TPS61305YFFT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
