TPS92201MDRLR TI LED Driver | SOT-563 | 40V, 1.5A, PWM Dimming

Product Overview

The TPS92201MDRLR is a high-performance, synchronous buck LED driver from Texas Instruments, designed for driving high-brightness LEDs with excellent efficiency and accuracy. Housed in a compact SOT-563 package, it integrates a 40V, 1.5A power switch and supports both analog and PWM dimming. The device operates over a wide input voltage range of 4.5V to 40V, making it suitable for automotive, industrial, and general lighting applications. Its constant-current regulation ensures uniform LED brightness, while features like cycle-by-cycle current limit and thermal shutdown enhance reliability.

Detailed Technical Specifications

Key Features

• Integrated 40V, 1.5A power MOSFET
• Wide input voltage range: 4.5V to 40V
• High efficiency up to 95%
• Analog and PWM dimming capability
• Cycle-by-cycle current limit and thermal shutdown
• Small SOT-563 package for space-constrained designs
• Constant-current regulation with ±5% accuracy

Target Applications

• Automotive lighting: headlights, daytime running lights (DRLs), taillights, interior ambient lighting
• Industrial lighting: LED bars, panel lights, street lighting
• General lighting: downlights, spotlights, portable lamps
• Display backlighting: LCD monitors, automotive dashboards
• 5G base station indicator lights

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TPS92201MDRLR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
