TS3V340DBQR TI Video Switch | 16-SSOP | 400MHz, 5V/3.3V

Product Overview

The TS3V340DBQR from Texas Instruments is a high-performance quad SPDT (Single Pole Double Throw) video switch designed for routing analog video signals in applications requiring high bandwidth and low on-state resistance. Housed in a compact 16-SSOP package, this device supports both 5V and 3.3V supply voltages, making it versatile for various video interface standards. With a bandwidth of 400MHz and low crosstalk, it ensures excellent signal integrity for composite video, S-video, and component video signals.

Detailed Technical Specifications

Key Features

• Quad SPDT switch configuration
• Wide bandwidth: 400 MHz
• Low on-state resistance: 10 Ω typical
• Low crosstalk and off isolation: -80 dB at 10 MHz
• Supports both 5V and 3.3V logic levels
• ESD protection: 2 kV HBM
• Rail-to-rail signal handling
• Fast switching speed: tON = 10 ns, tOFF = 5 ns

Target Applications

• Video signal routing in 5G base stations (e.g., for monitoring video feeds)
• Automotive dashboard displays (e.g., for switching between rearview camera and infotainment video)
• Professional video switchers and routers
• Security surveillance systems (e.g., DVR/NVR video input selection)
• Consumer electronics (e.g., TV, set-top boxes, gaming consoles)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TS3V340DBQR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
