UCC5630AMWP/2 TI SCSI Terminator | 9-Line, 2.7-5.5V, 110Ω

Product Overview

The UCC5630AMWP/2 from Texas Instruments is a 9-line SCSI (Small Computer System Interface) active terminator designed for high-speed parallel bus termination. It integrates 9 termination lines with 110Ω impedance, supporting single-ended SCSI applications. Operating from a 2.7V to 5.5V supply, it features low output capacitance and thermal shutdown protection. The device is available in a 20-pin SOIC package and is ideal for SCSI-1, SCSI-2, and Ultra SCSI systems.

Detailed Technical Specifications

Key Features

• 9-line active termination for single-ended SCSI
• Wide supply voltage range: 2.7V to 5.5V
• Low output capacitance minimizes signal distortion
• Thermal shutdown protection for reliability
• Compatible with SCSI-1, SCSI-2, and Ultra SCSI standards
• Compact 20-pin SOIC package

Target Applications

• SCSI bus termination in servers and storage arrays (e.g., Dell PowerEdge servers)
• High-speed data acquisition systems (e.g., National Instruments PXI chassis)
• Industrial controllers with SCSI interfaces (e.g., Siemens SIMATIC)
• Legacy SCSI peripherals like tape drives and scanners
