2ED020I12FAXUMA2 Infineon Gate Driver | PG-DSO-36-58 | 2A Peak Current, 1200V

Product Overview

The Infineon 2ED020I12FAXUMA2 is a high-voltage, high-speed dual-channel gate driver IC designed for driving IGBTs and MOSFETs in industrial and automotive applications. Housed in a compact PG-DSO-36-58 package, it delivers 2A peak output current per channel with reinforced isolation up to 1200V. This device integrates advanced protection features including desaturation detection, active Miller clamp, and under-voltage lockout (UVLO), ensuring robust and reliable operation in harsh environments.

Detailed Technical Specifications

Key Features

• Dual-channel isolated gate driver with 2A peak output current
• Reinforced isolation for 1200V working voltage
• Integrated desaturation detection for short-circuit protection
• Active Miller clamp to prevent false turn-on
• Under-voltage lockout (UVLO) with hysteresis
• Soft-off function during fault conditions
• Wide operating temperature range

Target Applications

• Industrial motor drives (e.g., Siemens SINAMICS G120)
• Solar inverters (e.g., SMA Sunny Boy)
• Uninterruptible power supplies (UPS) (e.g., APC Smart-UPS)
• Electric vehicle charging stations (e.g., ABB Terra)
• 5G base station power supplies (e.g., Huawei 5G BBU)
• Automotive traction inverters (e.g., Tesla Model 3)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for 2ED020I12FAXUMA2. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
