IR2011PBF Infineon Gate Driver IC | 8-PDIP | 200V Offset, 0.5A Peak

Product Overview

The IR2011PBF is a high-voltage, high-speed power MOSFET and IGBT driver with independent high- and low-side referenced output channels. Manufactured by Infineon Technologies, this device is housed in an 8-lead PDIP package and is designed for applications requiring high-side switching up to 200V. It features a floating channel designed for bootstrap operation, enabling efficient drive of N-channel power MOSFETs or IGBTs in half-bridge or full-bridge configurations. The IR2011PBF offers matched propagation delays and a shutdown input for enhanced control, making it suitable for a wide range of power conversion systems.

Detailed Technical Specifications

Key Features

• Floating channel for bootstrap operation up to 200V
• Integrated high- and low-side drivers with independent outputs
• Matched propagation delays for both channels
• Shutdown input for disabling outputs
• Undervoltage lockout (UVLO) for VCC and VBS
• 3.3V and 5V logic input compatible
• High noise immunity (dV/dt > 50V/ns)
• RoHS compliant (lead-free)

Target Applications

• Motor drives for industrial automation (e.g., servo drives for robotic arms)
• Switched-mode power supplies (SMPS) for telecom base stations (e.g., 5G remote radio units)
• DC-DC converters for automotive infotainment systems
• Class-D audio amplifiers for home theater systems
• Uninterruptible power supplies (UPS) for data centers
• Power inverters for solar microinverters

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for IR2011PBF. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
