IR2135JTRPBF Infineon Gate Driver IC | 44-PLCC, 32 leads (16.58X16.58) | 600V, 0.5A

Product Overview

The IR2135JTRPBF is a high-voltage, high-speed power MOSFET and IGBT gate driver IC from Infineon Technologies. It is designed for three-phase applications, providing three independent high-side and low-side output channels. The device features a floating channel design for bootstrap operation up to 600V, and it is capable of driving a wide range of power switches. The IR2135JTRPBF is housed in a 44-PLCC package with 32 leads, measuring 16.58mm x 16.58mm, offering a compact solution for motor drives, inverters, and power supplies.

Detailed Technical Specifications

Key Features

• Floating channel for bootstrap operation up to 600V
• Three independent high-side and low-side drivers
• Cross-conduction prevention logic
• Under-voltage lockout for both VCC and VBS
• Matched propagation delays for all channels
• High noise immunity
• Lead-free and RoHS compliant

Target Applications

• Three-phase motor drives for industrial automation (e.g., servo drives, conveyor systems)
• Uninterruptible power supplies (UPS) for data centers
• Air conditioning and refrigeration compressors
• Electric vehicle (EV) traction inverters
• 5G base station power supplies
• Solar inverters for photovoltaic systems

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for IR2135JTRPBF. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
