TLE94110ESXUMA1 Infineon Motor Driver | PG-TSDSO-24 | 1.5A, 40V, Half-Bridge

Product Overview

The TLE94110ESXUMA1 is a highly integrated half-bridge driver IC from Infineon, designed for automotive and industrial DC motor control applications. Housed in a compact PG-TSDSO-24 package, it delivers up to 1.5A continuous output current and operates over a wide supply voltage range from 5.5V to 40V. The device features low RDS(on) of 0.5Ω (typ) for high efficiency, integrated protection functions (overcurrent, overtemperature, undervoltage), and a SPI interface for advanced diagnostics and control. It is AEC-Q100 qualified, making it suitable for harsh automotive environments.

Detailed Technical Specifications

Key Features

• Single half-bridge driver with integrated power MOSFETs
• Low quiescent current (typ 1µA) in sleep mode
• SPI for configuration and fault reporting
• Adjustable slew rate for EMI optimization
• Cross-conduction prevention
• Active freewheeling for fast demagnetization
• Under-voltage lockout (UVLO)
• Overcurrent and overtemperature shutdown
• Short-circuit protection to GND and VS

Target Applications

• Automotive: HVAC flap control, headlamp leveling, fuel pump, transmission actuators
• Industrial: 5G base station antenna tilting, robotic arm joints, conveyor belt drives
• Consumer: Dashboard stepper motors, seat adjustment, window lift

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TLE94110ESXUMA1. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
