LD56020J100R ST LDO Regulator | 4-覆晶（0.69x0.69） | 1A, 1.0V Output

Product Overview

The LD56020J100R from STMicroelectronics is a high-performance, low-dropout (LDO) linear voltage regulator designed for space-constrained applications. Housed in a compact 4-bump flip-chip package measuring just 0.69x0.69 mm, it delivers a fixed output voltage of 1.0V with a maximum output current of 1A. This regulator combines low quiescent current, high PSRR, and excellent transient response, making it ideal for powering sensitive analog and digital loads in portable and industrial electronics.

Detailed Technical Specifications

Key Features

• Ultra-small 4-bump flip-chip package (0.69x0.69mm) for space-constrained designs
• Low dropout voltage: 200mV typical at 1A load
• Low quiescent current: 55µA typical, ideal for battery-powered devices
• High PSRR: 70dB at 1kHz for clean power supply
• Low output noise: 30µVrms, suitable for RF and audio circuits
• Stable with ceramic output capacitors (1µF min)
• Overcurrent and thermal protection

Target Applications

• 5G base station power management: powering RF transceivers and FPGAs
• Automotive dashboard displays: providing clean 1.0V supply for processors
• Portable medical devices: low noise for sensor analog front-ends
• IoT modules: efficient regulation for battery-powered sensors
• Industrial control systems: stable voltage for microcontrollers

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for LD56020J100R. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
