STM8S005K6T6CTR ST Microcontroller | 32-LQFP (7x7) | 32KB Flash, 16MHz

Product Overview

The STM8S005K6T6CTR is a high-performance 8-bit microcontroller from STMicroelectronics, featuring an advanced STM8 core with a 16 MHz CPU clock. It offers 32 KB of Flash program memory, 2 KB of RAM, and 1 KB of EEPROM. Housed in a compact 32-pin LQFP package (7x7 mm), this device is designed for cost-sensitive applications requiring robust performance and rich peripherals.

Detailed Technical Specifications

Key Features

• Advanced STM8 core with Harvard architecture and 3-stage pipeline
• Up to 16 MIPS throughput at 16 MHz
• Embedded single-wire debug module (SWIM)
• Clock sources: internal 16 MHz RC, external crystal, or resonator
• Reset circuitry: power-on reset, brown-out reset, watchdog
• Low power modes: Wait, Active Halt, Halt
• Rich analog: 10-bit ADC with internal reference
• Robust I/O: 25 I/Os with programmable pull-ups and interrupt capability
• Communication: SPI, I2C, UART with LIN support
• Up to 16 external interrupt sources

Target Applications

The STM8S005K6T6CTR is ideal for a wide range of applications including: industrial control (e.g., PLC modules, motor control), consumer electronics (e.g., smart home devices, remote controls), automotive aftermarket (e.g., dashboard controllers, sensor modules), and communication infrastructure (e.g., 5G base station power management, IoT edge nodes). Its rich peripheral set and low power consumption make it suitable for battery-operated devices and real-time control systems.

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for STM8S005K6T6CTR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

STM8S005K6T6CTR 是意法半導體推出的一款高性能8位微控制器，採用先進的 STM8 內核，CPU 時鐘高達 16 MHz。它提供 32 KB 的 Flash 程序存儲器、2 KB 的 RAM 和 1 KB 的 EEPROM。該器件採用緊湊的 32 引腳 LQFP 封裝（7x7 mm），專為需要強大性能和豐富外設的成本敏感型應用而設計。

詳細技術參數

核心特性

• 先進的 STM8 內核，哈佛架構，3級流水線
• 16 MHz 下高達 16 MIPS 吞吐量
• 嵌入式單線調試模塊 (SWIM)
• 時鐘源：內部 16 MHz RC，外部晶體或諧振器
• 復位電路：上電復位、欠壓復位、看門狗
• 低功耗模式：等待、活躍停機、停機
• 豐富的模擬功能：10位 ADC，帶內部參考
• 強大的 I/O：25 個 I/O，可編程上拉和中斷能力
• 通信：SPI, I2C, UART，支持 LIN
• 最多 16 個外部中斷源

典型應用場景

STM8S005K6T6CTR 適用於廣泛的應用，包括：工業控制（例如 PLC 模塊、電機控制）、消費電子（例如智能家居設備、遙控器）、汽車後市場（例如儀表板控制器、傳感器模塊）以及通信基礎設施（例如 5G 基站電源管理、IoT 邊緣節點）。其豐富的外設和低功耗特性使其非常適合電池供電設備和實時控制系統。

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 STM8S005K6T6CTR 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
