DRV8220DRLR TI Motor Driver | SOT-563 | 1.65-5.5V, 1.5A

Product Overview

The DRV8220DRLR from Texas Instruments is a low-voltage, low-RDS(on) H-bridge motor driver designed for driving one brushed DC motor or one winding of a stepper motor. It operates from a supply voltage range of 1.65V to 5.5V and can deliver up to 1.5A peak current. The device is housed in a compact SOT-563 package, making it ideal for space-constrained applications. It features low quiescent current, integrated protection functions, and simple PWM control interface.

Detailed Technical Specifications

Key Features

• Wide supply voltage range: 1.65V to 5.5V
• Low RDS(on): 0.6Ω typical at 5V
• High output current: 1.5A peak
• Low quiescent current: 1.5 μA in sleep mode
• Integrated protection: overcurrent, overtemperature, undervoltage lockout
• Simple PWM control interface
• Compact SOT-563 package

Target Applications

• Portable and battery-powered devices (e.g., smart locks, toys)
• 5G base station antenna tilt control
• Automotive dashboard actuators
• Medical devices (e.g., infusion pumps)
• Industrial automation (e.g., valve control)
