HD3SS460IRHRR TI USB Type-C Mux | 28-WQFN (5.5X3.5) | 10.2Gbps, 2:1/1:2

Product Overview

The HD3SS460IRHRR is a high-speed USB Type-C mux/demux from Texas Instruments, designed to support USB 3.1 Gen 2 (10 Gbps) and DisplayPort 1.4 (8.1 Gbps) alternate mode switching. It features a 2:1/1:2 differential switch configuration, enabling seamless signal routing for USB Type-C connectors. The device operates over a wide supply range of 3.0V to 3.6V and is housed in a compact 28-pin WQFN package (5.5mm x 3.5mm). With low insertion loss and high bandwidth, it is ideal for applications requiring high-speed data and video signal switching.

Detailed Technical Specifications

Key Features

• Supports USB 3.1 Gen 2 (10 Gbps) and DisplayPort 1.4 (8.1 Gbps)
• Low insertion loss and high bandwidth for signal integrity
• Integrated 50-Ω termination resistors
• Low power consumption: 1.5 mW (typical)
• ESD protection: 2 kV HBM
• Small footprint package for space-constrained designs

Target Applications

• USB Type-C hubs and docking stations (e.g., Dell WD19TB)
• Notebook and tablet computers (e.g., Dell XPS 13)
• 5G base station control boards
• Automotive infotainment dashboards
• Video conferencing systems (e.g., Logitech Rally)
• Industrial embedded systems
