MUX506IPWR TI Analog Multiplexer | 28-TSSOP | 16:1, 100Ohm, 5V

Product Overview

The MUX506IPWR from Texas Instruments is a high-performance 16:1 single-ended analog multiplexer designed for precision signal routing in industrial and communication systems. Housed in a compact 28-TSSOP package, it offers low on-resistance (100Ω typical) and wide supply voltage range (5V to 36V). This device ensures minimal signal distortion and high ESD protection, making it ideal for data acquisition, test equipment, and audio/video switching.

Detailed Technical Specifications

Key Features

• Low on-resistance (100Ω) with flatness of 10Ω over signal range
• Wide supply range: 5V to 36V single or dual supplies
• Low leakage currents (0.5nA typical) for high precision
• High bandwidth (200MHz) suitable for video and RF signals
• Break-before-make switching prevents channel overlap
• ESD protection up to 2kV HBM
• Industry-standard 28-TSSOP package for space-constrained designs

Target Applications

• 5G base station: RF signal routing and antenna switching
• Automotive dashboard: sensor multiplexing for temperature, pressure, and position
• Data acquisition systems: multi-channel analog input selection
• Audio/video switching: home theater systems and professional AV equipment
• Test and measurement: automated test equipment (ATE) for signal routing

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for MUX506IPWR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
