PCI7402ZHK TI PCI Bridge | 216-BGAMICROSTAR (16x16) | 32-bit, 33MHz PCI, 2-Channel

Product Overview

The PCI7402ZHK from Texas Instruments is a high-performance PCI-to-PCI bridge designed to provide a seamless interface between PCI buses. It supports 32-bit, 33MHz PCI operation and features two independent PCI bus segments, enabling system designers to expand the number of PCI slots or isolate bus traffic for improved performance. Housed in a compact 216-ball BGA MICROSTAR package (16x16mm), this device is ideal for space-constrained applications requiring reliable PCI bridging.

Detailed Technical Specifications

Key Features

• Dual PCI bus segments for increased slot count or bus isolation
• 32-bit, 33MHz PCI interface compliant with PCI 2.3
• Low power consumption with 3.3V core and I/O
• Compact 216-ball BGA MICROSTAR package (16x16mm) for space-saving designs
• Supports bus master and target operations
• Configurable arbitration for each PCI segment
• Integrated PCI configuration registers

Target Applications

• 5G base station control cards requiring additional PCI slots
• Automotive infotainment systems (e.g., dashboard controllers) needing PCI expansion
• Industrial embedded computers with multiple PCI peripherals
• Network routers and switches for PCI bus isolation
• Medical imaging equipment with PCI-based data acquisition

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for PCI7402ZHK. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
