SN74ABTE16245DGG TI Bus Transceiver | 16-bit | 3.3V, 5V Tolerant

Product Overview

The SN74ABTE16245DGG is a 16-bit (dual octal) non-inverting bus transceiver from Texas Instruments, designed for asynchronous communication between data buses. It features 3-state outputs and operates with a supply voltage range of 4.5V to 5.5V, while being 5V tolerant on inputs. The device is part of the ABTE family, offering enhanced drive capability and low power consumption. It is ideal for bidirectional data flow in high-speed systems, with flow-through pinout for easy PCB layout.

Detailed Technical Specifications

Key Features

• 16-bit bidirectional bus transceiver with 3-state outputs
• 5V tolerant inputs for mixed-voltage systems
• High drive capability: -32 mA / 64 mA
• Low propagation delay: 3.5 ns typical
• Flow-through pinout for simplified PCB routing
• ESD protection exceeds JESD 22
• Supports live insertion and withdrawal

Target Applications

• 5G base station control boards
• Automotive dashboard infotainment systems
• Industrial PLC backplane communication
• Data center server memory interfaces
• Telecommunications line cards

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74ABTE16245DGG. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
