SN74AC7541DGSR TI Buffer/Driver | 20-VSSOP | 8-Ch, 2V-6V, 24mA

Product Overview

The SN74AC7541DGSR is a high-performance octal buffer and line driver from Texas Instruments, designed for 2V to 6V VCC operation. It features 8-bit non-inverting outputs with 3-state capability, making it ideal for bus-oriented applications. Housed in a compact 20-VSSOP package, this device offers balanced propagation delays and high drive capability (up to 24mA at 5V). It is part of the AC logic family, providing improved speed and lower power consumption compared to standard CMOS logic.

Detailed Technical Specifications

Key Features

• Wide operating voltage range: 2V to 6V
• High drive capability: ±24mA at 5V
• Low propagation delay: 6.5ns max at 5V, 50pF
• 3-state outputs for bus-oriented applications
• Inputs accept voltages up to 6V regardless of VCC
• ESD protection exceeds 2000V per MIL-STD-883, Method 3015
• Available in space-saving 20-VSSOP package

Target Applications

• 5G base station control logic: buffering address/data lines between FPGA and RF transceivers (e.g., TI AFE7685)
• Automotive dashboard display: driving LED indicators and segment displays in instrument clusters
• Industrial PLC I/O modules: buffering sensor inputs and actuator outputs
• Medical imaging equipment: signal conditioning for data acquisition systems
• Consumer electronics: level shifting and bus isolation in smart home hubs

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74AC7541DGSR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
