SN74HC175APW TI Flip-Flop | 16-TSSOP | 4-Bit, D-Type, 2V-6V

Product Overview

The SN74HC175APW is a high-speed quad D-type flip-flop with complementary outputs from Texas Instruments. It features a common clock and asynchronous clear, making it ideal for data storage and transfer applications. The device operates over a wide voltage range of 2V to 6V and is characterized for operation from -40°C to +85°C. Housed in a compact 16-TSSOP package, it is suitable for space-constrained designs.

Detailed Technical Specifications

Key Features

• 4-bit D-type flip-flop with clear
• Complementary outputs (Q and Q̅)
• Wide operating voltage range: 2V to 6V
• High noise immunity: typical VNH = 28% of Vcc
• Low power consumption: 80-μA max ICC
• Edge-triggered clock input
• Asynchronous clear function
• Industry-standard pinout

Target Applications

• Data storage and transfer in 5G base stations (e.g., buffer registers)
• Automotive dashboard displays (e.g., latch for segment drivers)
• Industrial control systems (e.g., PLC I/O modules)
• Consumer electronics (e.g., smart home hubs)
• Medical devices (e.g., patient monitoring systems)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74HC175APW. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

SN74HC175APW 是德州儀器 (TI) 的一款高速四路 D 型觸發器，具有互補輸出。它採用公共時鐘和非同步清零，非常適合數據存儲和傳輸應用。該器件可在 2V 至 6V 的寬電壓範圍內工作，並在 -40°C 至 +85°C 的溫度範圍內保證性能。採用緊湊的 16-TSSOP 封裝，適合空間受限的設計。

詳細技術參數

核心特性

• 4 位 D 型觸發器，帶清零功能
• 互補輸出 (Q 和 Q̅)
• 寬工作電壓範圍：2V 至 6V
• 高抗噪能力：典型 VNH = 28% Vcc
• 低功耗：最大 ICC 80 μA
• 邊沿觸發時鐘輸入
• 非同步清零功能
• 業界標準引腳排列

典型應用場景

• 5G 基站中的數據存儲和傳輸（例如緩衝寄存器）
• 汽車儀表板顯示（例如段驅動器的鎖存器）
• 工業控制系統（例如 PLC I/O 模塊）
• 消費電子產品（例如智能家居中心）
• 醫療設備（例如病人監護系統）

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 SN74HC175APW 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
