SN74HC623NS TI Non-Inverting Transceiver | 20-SO | 8-Bit, 2V to 6V

Product Overview

The SN74HC623NS is a high-performance octal bus transceiver from Texas Instruments, featuring non-inverting 3-state outputs. It is designed for asynchronous communication between two data buses, with direction control via the DIR input and output enable via the OE input. The device operates over a wide voltage range of 2V to 6V, making it suitable for a variety of logic-level applications. Housed in a 20-pin SO package, it offers a compact solution for bidirectional data flow in digital systems.

Detailed Technical Specifications

Key Features

• Non-inverting 8-bit bus transceiver
• Separate direction (DIR) and output enable (OE) controls
• Wide operating voltage range: 2V to 6V
• High noise immunity: typical 30% of VCC
• Low power consumption: 80 µA max ICC
• Compatible with TTL levels
• ESD protection exceeds 2000V per MIL-STD-883

Target Applications

The SN74HC623NS is ideal for bidirectional data transfer in systems such as 5G base station control boards, automotive dashboard displays, industrial PLCs, and networking equipment. It can be used to interface between microcontrollers and memory modules, or to drive data buses in telecommunications infrastructure.

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74HC623NS. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
