SN74HC664NT TI Shift Register | 8-bit, Serial-In/Parallel-Out, 2V-6V

Product Overview

The SN74HC664NT is a high-speed 8-bit shift register from Texas Instruments, designed for serial-to-parallel data conversion. It operates over a wide voltage range of 2V to 6V, making it suitable for battery-powered and industrial applications. The device features a serial input (DS), parallel outputs (Q0–Q7), and a shift/load control (SH/LD) that allows either shifting or parallel loading. With a typical clock frequency of 25 MHz at 5V, it provides efficient data handling for various digital systems.

Detailed Technical Specifications

Key Features

• 8-bit serial-in, parallel-out shift register
• Wide operating voltage range: 2V to 6V
• High-speed operation: 25 MHz typical clock frequency at 5V
• Shift and parallel load capability via SH/LD input
• Asynchronous master reset (MR) for clearing registers
• Outputs can drive up to 10 LSTTL loads
• Low power consumption: 80 µA max ICC
• ESD protection exceeds 2000V per MIL-STD-883

Target Applications

• 5G base station control logic: used for serial data transfer between FPGA and RF modules
• Automotive dashboard display: driving LED segments or LCD backlight control
• Industrial automation: PLC I/O expansion for sensor data collection
• Consumer electronics: remote control receiver decoding
• Medical devices: patient monitoring system data acquisition

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74HC664NT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
