SN74LVC1G10DBVR TI Single 3-Input NAND Gate | SOT-23-6 | 1.65V-5.5V, 5ns

Product Overview

The SN74LVC1G10DBVR is a single 3-input NAND gate from Texas Instruments, designed for 1.65-V to 5.5-V VCC operation. This device is fabricated with advanced LVC technology, offering low power consumption and high speed. The SN74LVC1G10DBVR performs the Boolean function Y = A • B • C or Y = A + B + C in positive logic. It is available in a small SOT-23-6 package, making it ideal for space-constrained applications.

Detailed Technical Specifications

Key Features

• Wide operating voltage range: 1.65 V to 5.5 V
• Low power consumption: 10 µA max ICC
• High speed: tpd 5 ns typical at 3.3 V
• Schmitt-trigger inputs for noise immunity
• ±24 mA output drive at 3.3 V
• Latch-up performance exceeds 250 mA per JESD 17
• ESD protection exceeds JESD 22

Target Applications

• 5G base station control logic
• Automotive dashboard display control
• Portable electronics: smartphones, tablets
• Industrial sensor interfaces
• IoT edge devices
• Signal gating and conditioning
