SN74LVC3G04YZPR TI Inverter | 8-DSBGA | 1.65V-5.5V, 24mA

Product Overview

The SN74LVC3G04YZPR from Texas Instruments is a triple inverter gate designed for low-voltage, high-speed logic applications. Housed in a compact 8-DSBGA package, it operates over a wide supply voltage range of 1.65V to 5.5V, making it suitable for battery-powered and portable devices. The device features balanced propagation delays and high output drive capability of up to 24mA at 3.3V, ensuring reliable performance in noise-sensitive environments.

Detailed Technical Specifications

Key Features

• Wide operating voltage range: 1.65V to 5.5V
• High output drive: ±24mA at 3.3V
• Low propagation delay: 3.6ns max at 3.3V
• Inputs accept voltages up to 5.5V regardless of VCC
• ESD protection exceeds JESD 22 (2000V HBM, 1000V CDM)
• Latch-up performance exceeds 100mA per JESD 78, Class II
• Ultra-small package: 8-DSBGA (1.9mm x 0.9mm)
• Green product and RoHS compliant

Target Applications

The SN74LVC3G04YZPR is ideal for a variety of applications including:

• 5G base station control logic
• Automotive dashboard displays
• Portable medical devices (e.g., glucose meters)
• Industrial sensor interfaces
• Smart home hubs
• Battery-powered IoT nodes

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LVC3G04YZPR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
