SN74LVCR162245KR TI Bus Transceiver | 56-BGA (7x4.5) | 16-bit, 3.3V, Non-Inverting

Product Overview

The SN74LVCR162245KR is a 16-bit (dual octal) non-inverting bus transceiver from Texas Instruments, designed for 3.3-V VCC operation with 5-V tolerant I/Os. It features two separate supply rails (VCCA and VCCB) for level translation between 1.65-V to 3.6-V domains. Packaged in a compact 56-ball BGA MICROSTAR JUNIOR (7x4.5 mm), it is ideal for space-constrained applications requiring bidirectional data flow and controlled impedance.

Detailed Technical Specifications

Key Features

• Bidirectional voltage-level translation between 1.65-V and 3.6-V domains
• 5-V tolerant I/Os for mixed-voltage systems
• Low power consumption with ICC of 10 µA max
• Bus hold on data inputs eliminates external pull-up resistors
• ESD protection exceeds JESD 22 (2000-V HBM, 1000-V CDM)
• Latch-up performance exceeds 100 mA per JESD 78

Target Applications

• 5G base station control boards (e.g., interfacing FPGA with baseband processor)
• Automotive dashboard display modules (e.g., connecting MCU to LCD driver)
• Industrial PLC I/O modules (e.g., level translation between 3.3-V and 1.8-V sensors)
• Networking switches and routers (e.g., bridging different voltage domains on line cards)
• Portable medical devices (e.g., battery-powered patient monitors)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LVCR162245KR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
