SN75447D TI Peripheral Driver | 8-SOIC | 500mA Output, 50V

Product Overview

The SN75447D is a high-voltage, high-current peripheral driver from Texas Instruments, designed to interface between low-level logic circuits and high-power loads. Housed in an 8-pin SOIC package, it integrates four independent Darlington transistor pairs with open-collector outputs, each capable of sinking up to 500 mA and withstanding up to 50 V. This device is ideal for driving relays, solenoids, stepper motors, and incandescent lamps in industrial and automotive applications.

Detailed Technical Specifications

Key Features

• Four Darlington transistor pairs with open-collector outputs
• High output current: 500 mA per channel
• High output voltage: 50 V
• Integrated suppression diodes for inductive loads
• TTL/CMOS compatible inputs
• Thermal shutdown protection
• Low standby power consumption

Target Applications

• Industrial automation: PLC output modules, relay drivers
• Automotive: dashboard indicator drivers, solenoid actuators
• Consumer electronics: printer head drivers, stepper motor drivers
• Telecommunications: 5G base station power management, line drivers
• Lighting: LED display drivers, incandescent lamp drivers

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN75447D. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
