SNJ54ACT11241FK TI Buffer/Line Driver | 20-Bit, 3-State, Non-Inverting

Product Overview

The SNJ54ACT11241FK is a high-performance 20-bit buffer and line driver from Texas Instruments, designed for military and aerospace applications. It features 3-state outputs, non-inverting logic, and operates over a wide voltage range of 4.5V to 5.5V. This device is part of the ACT family, offering advanced CMOS technology with TTL-compatible inputs. The SNJ54ACT11241FK is ideal for driving heavily loaded buses and is available in a ceramic flatpack package (FK) for enhanced reliability in harsh environments.

Detailed Technical Specifications

Key Features

• 20-bit non-inverting buffer/line driver with 3-state outputs
• Advanced CMOS technology (ACT) with TTL-compatible inputs
• High drive capability: ±24mA output current
• Low propagation delay: 6.5ns typical
• Wide operating temperature range: -55°C to +125°C
• ESD protection exceeds 2000V per MIL-STD-883
• Available in ceramic flatpack for high reliability

Target Applications

• Military communication systems (e.g., AN/PRC-117G manpack radio)
• Aerospace avionics (e.g., flight control computers in F-16)
• 5G base station control logic (e.g., Nokia AirScale baseband unit)
• Industrial automation (e.g., Siemens S7-1500 PLC backplane)
• High-reliability data buses (e.g., MIL-STD-1553 bus interface)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SNJ54ACT11241FK. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
