SNJ54AHC157W TI Logic Gates | 2V to 5.5V, 4-ch 2-input MUX

Product Overview

The SNJ54AHC157W is a high-speed quad 2-input multiplexer from Texas Instruments, designed for 2V to 5.5V operation. It features four multiplexers with common select and enable logic, providing a single-pole double-throw (SPDT) function per channel. The device is fabricated using advanced CMOS technology to achieve high speed while maintaining low power dissipation. It is ideal for bus-oriented applications and general-purpose data selection.

Detailed Technical Specifications

Key Features

• Quad 2-input multiplexer with common select and enable
• Wide operating voltage range: 2V to 5.5V
• High speed: tpd = 7.5 ns typ at 5V
• Low power consumption: ICC = 4 µA max
• Inputs accept voltages up to 5.5V
• Outputs drive up to 8 mA at 5V
• ESD protection exceeds 2000V per MIL-STD-883
• Available in hermetic ceramic flatpack (W package)

Target Applications

• Data routing in 5G base station control boards
• Signal selection in automotive dashboard displays
• Bus multiplexing in industrial PLCs
• General-purpose logic in aerospace avionics
• Test equipment channel switching

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SNJ54AHC157W. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
