SNJ54HC09FK TI Logic Gates | Quad 2-Input AND Gate | 2V to 6V, High-Speed

Product Overview

The SNJ54HC09FK is a high-speed quad 2-input AND gate from Texas Instruments, fabricated using advanced silicon-gate CMOS technology. It operates over a wide supply voltage range of 2V to 6V, providing compatibility with TTL logic levels while maintaining low power consumption. The device features balanced propagation delays and high noise immunity, making it suitable for a variety of digital logic applications. Housed in a ceramic flatpack (FK) package, it is designed for military and high-reliability environments, offering enhanced thermal performance and durability.

Detailed Technical Specifications

Key Features

• Quad 2-input AND gate logic function
• Wide operating voltage range: 2V to 6V
• High noise immunity: typically VNIH = VNIL = 28% of VCC
• Low power consumption: 20µA max ICC
• Balanced propagation delays: tPLH ≈ tPHL
• TTL-compatible inputs: can drive 1 LSTTL load
• High-reliability ceramic flatpack package
• Military temperature range: -55°C to +125°C

Target Applications

The SNJ54HC09FK is ideal for use in high-reliability digital systems, including:

• 5G base station control logic
• Avionics and aerospace data processing
• Military communication systems
• Industrial automation controllers
• Automotive dashboard electronics (e.g., infotainment clusters)
• Medical device logic circuits

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SNJ54HC09FK. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
