THS7320IYHCT TI Video Amplifier | 9-DSBGA (0.96x0.96) | 3-Ch, 6th-Order Filter

Product Overview

The THS7320IYHCT is a high-performance, 3-channel video amplifier from Texas Instruments, designed for driving video signals in applications requiring low power and small footprint. Housed in a compact 9-DSBGA (0.96x0.96 mm) package, it integrates a 6th-order Butterworth filter with selectable cutoff frequencies (9.5 MHz or 36 MHz) and offers rail-to-rail output. The device operates from a single 2.7V to 5.5V supply, making it ideal for battery-powered and space-constrained designs.

Detailed Technical Specifications

Key Features

• Three independent video amplifier channels with integrated filters
• Selectable 6th-order Butterworth filter: 9.5 MHz for SDTV or 36 MHz for HDTV
• Rail-to-rail output swing for maximum dynamic range
• Low power consumption: 4.5 mA per channel (typical)
• Shutdown mode for power saving (<1 μA)
• Internal gain of 6 dB (2 V/V) for standard video levels
• Small footprint 9-DSBGA package saves board space

Target Applications

• Video line drivers for set-top boxes and digital video recorders (e.g., TiVo Bolt)
• Automotive infotainment systems (e.g., Tesla Model 3 center display)
• Portable media players and tablets (e.g., iPad Pro video output)
• Security camera systems (e.g., Hikvision DS-2CD2T47G2-L)
• Video surveillance DVRs (e.g., Dahua DHI-NVR4108-8P-4KS2)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for THS7320IYHCT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
