TLC5940PWPR TI LED Driver | 28-HTSSOP | 16-Channel, Constant Current

Product Overview

The TLC5940PWPR is a 16-channel constant-current sink LED driver from Texas Instruments (TI), designed for high-performance LED control in applications requiring precise current regulation and grayscale control. Housed in a compact 28-HTSSOP package, it integrates a 16-bit shift register, data latches, and constant-current output stages. Each channel can be independently adjusted via serial interface, enabling smooth PWM dimming and pattern generation. The device operates over a wide supply voltage range (3.0V to 5.5V) and supports output currents up to 120 mA per channel, making it suitable for both low-power and medium-power LED arrays.

Detailed Technical Specifications

Key Features

• 16 constant-current sink outputs with 120 mA capability
• 16-bit grayscale PWM control for smooth dimming
• Serial data interface with 30 MHz clock frequency
• Built-in thermal shutdown and error detection
• Output current programmable via external resistor
• Low power consumption: 10 mA (typical) at 5 V
• RoHS compliant and lead-free

Target Applications

• LED video displays and signage (e.g., indoor/outdoor panels)
• Automotive lighting (e.g., dashboard backlight, ambient lighting)
• Industrial control panels and indicator lights
• 5G base station status indicators
• Consumer electronics (e.g., smart home LED strips)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TLC5940PWPR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
