TPS2561ADRCR TI Power Distribution | 10-VSON(3x3) | 0.5A-2.5A, 2.7-6.5V

Product Overview

The TPS2561ADRCR from Texas Instruments is a dual-channel, current-limited power distribution switch designed for applications requiring precise current limiting and power management. Housed in a compact 10-VSON (3x3 mm) package, it provides two independent 0.5 A to 2.5 A adjustable current-limit channels, operating over a supply voltage range of 2.7 V to 6.5 V. This device integrates N-channel MOSFETs with low on-resistance (typically 73 mΩ per channel) to minimize power loss and heat dissipation. It features programmable current limiting via external resistors, thermal shutdown protection, and under-voltage lockout (UVLO). The TPS2561ADRCR is ideal for USB ports, industrial automation, and consumer electronics where reliable power distribution and fault protection are critical.

Detailed Technical Specifications

Key Features

• Dual-channel independent current limiting with adjustable threshold
• Low on-resistance (73 mΩ) for minimal voltage drop
• Wide input voltage range (2.7 V to 6.5 V)
• Accurate current limit (±8% typical)
• Thermal shutdown and under-voltage lockout protection
• Reverse current blocking prevents back-feeding
• Small 10-VSON package saves board space
• Enable pins for individual channel control

Target Applications

• USB ports (USB 2.0/3.0) in laptops, docking stations, and hubs
• 5G base station power distribution modules
• Industrial automation controllers and PLCs
• Automotive infotainment and dashboard systems
• Consumer electronics like smart speakers and gaming consoles
• Power management for IoT gateways and edge devices
