TS3V330DBQR TI Video Switch | 16-SSOP | 4-Ch SPDT, 300MHz BW

Product Overview

The TS3V330DBQR from Texas Instruments is a high-performance 4-channel single-pole double-throw (SPDT) video switch designed for routing composite video, S-video, and RGB signals. Housed in a compact 16-pin SSOP package, it offers wide bandwidth (300 MHz) and low on-state resistance (5 Ω typical), making it ideal for video signal multiplexing in consumer and industrial applications. The device operates from a single 3.3V supply and features bidirectional signal flow with low crosstalk and high off-isolation.

Detailed Technical Specifications

Key Features

• Wide bandwidth: 300 MHz supports high-resolution video
• Low on-state resistance: 5 Ω minimizes signal attenuation
• Low crosstalk and high off-isolation: ensures signal integrity
• Single-supply operation: 3.3V compatible with modern logic
• Bidirectional signal path: flexible routing
• ESD protection: 2 kV HBM
• RoHS compliant

Target Applications

• Video signal routing in 5G base stations (e.g., remote radio units)
• Automotive infotainment systems (e.g., dashboard displays, rear-seat entertainment)
• Security surveillance systems (e.g., DVR multiplexers)
• Professional video equipment (e.g., switchers, routers)
• Consumer electronics (e.g., HDTV, set-top boxes)
