TS5A22362YZPR TI Analog Switch IC | 10-DSBGA | 0.5Ω, SPDT, 2-Ch

Product Overview

The TS5A22362YZPR from Texas Instruments is a high-performance, dual-channel SPDT analog switch designed for precision signal routing in audio and data acquisition systems. Housed in a compact 10-DSBGA package, it offers low on-state resistance (0.5Ω typical) and excellent linearity, making it ideal for low-distortion audio switching and multiplexing applications. The device operates over a wide supply voltage range of 1.65V to 5.5V, ensuring compatibility with both low-voltage and standard logic levels.

Detailed Technical Specifications

Key Features

• Low on-state resistance (0.5Ω typical) minimizes signal attenuation
• Low THD+N (0.002%) for high-fidelity audio applications
• Wide supply voltage range (1.65V to 5.5V) supports various logic levels
• High bandwidth (100 MHz) suitable for video and RF switching
• Excellent off isolation (-70 dB) and crosstalk (-90 dB) at 1 MHz
• Break-before-make switching prevents momentary short circuits
• Ultra-small 10-DSBGA package saves board space
• ESD protection (2 kV HBM)

Target Applications

• Audio signal routing in 5G base stations (e.g., audio codec line-out switching)
• Portable audio devices (e.g., smartphone headphone jack multiplexing)
• Data acquisition systems (e.g., sensor signal multiplexing in industrial IoT)
• Automotive infotainment (e.g., dashboard audio source selection)
• Medical instrumentation (e.g., ultrasound signal routing)
• Test and measurement equipment (e.g., oscilloscope channel switching)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TS5A22362YZPR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
