TSC2046IZQCR TI Touchscreen Controller | 48-BGAMICROSTARJUNIOR(4x4) | 4-Wire, 12-Bit

Product Overview

The TSC2046IZQCR is a low-power, 4-wire resistive touchscreen controller from Texas Instruments, designed for portable and industrial applications. It features a 12-bit SAR ADC with a maximum sampling rate of 125 kHz, supporting single-ended and differential analog inputs. The device operates from a 2.2V to 5.25V supply and includes an on-chip 2.5V reference, touch-pressure measurement, and a temperature sensor. Housed in a compact 48-BGA MICROSTAR JUNIOR (4x4 mm) package, it is ideal for space-constrained designs.

Detailed Technical Specifications

Key Features

• 4-wire resistive touchscreen interface
• 12-bit SAR ADC with 125 kSPS throughput
• Low power: 0.5 mW at 2.7V
• On-chip 2.5V reference and temperature sensor
• Touch-pressure measurement capability
• SPI-compatible serial interface
• Small 48-BGA package (4x4 mm)
• Wide supply voltage range: 2.2V to 5.25V

Target Applications

• 5G base station control panels
• Automotive dashboard touchscreens
• Portable media players (e.g., iPod-like devices)
• Industrial human-machine interfaces (HMIs)
• Medical handheld devices (e.g., glucose meters)
• Point-of-sale (POS) terminals

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TSC2046IZQCR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
