TUSB1146RGFTQ1 TI USB Type-C Redriver | 40-VQFN (7x5) | 10Gbps, DP Alt Mode

Product Overview

The TUSB1146RGFTQ1 is a high-performance USB Type-C redriver from Texas Instruments, designed to support USB 3.2 Gen 2 (10 Gbps) and DisplayPort Alt Mode. It is housed in a compact 40-pin VQFN package (7x5 mm) and is AEC-Q100 qualified for automotive applications. The device provides signal conditioning to extend the reach of high-speed signals over longer PCB traces or cables, ensuring compliance with USB and DP standards.

Detailed Technical Specifications

Key Features

• Supports USB 3.2 Gen 2 (10 Gbps) and DisplayPort 1.4 (HBR3)
• Integrated 50-ohm termination and AC coupling capacitors
• Automatic direction detection for USB Type-C
• Low power consumption: 300 mW typical
• I2C control for configuration and status monitoring
• ESD protection: ±8 kV contact, ±15 kV air

Target Applications

• Automotive infotainment systems (e.g., dashboard display units)
• 5G base station control modules
• USB Type-C docking stations and hubs
• Industrial embedded systems requiring high-speed data transfer
• Consumer electronics with USB-C connectivity

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TUSB1146RGFTQ1. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
