TXB0101DRLR TI Voltage Level Translator | SOT-5X3 | 1.2V-3.6V, 1.65V-5.5V

Product Overview

The TXB0101DRLR from Texas Instruments is a 1-bit bidirectional voltage-level translator designed for applications requiring voltage translation between different logic levels. It operates with a wide supply voltage range on the A port (1.2V to 3.6V) and B port (1.65V to 5.5V), making it suitable for interfacing low-voltage ASICs/FPGAs with higher-voltage peripherals. The device features automatic direction sensing, eliminating the need for a direction control pin. Housed in a compact SOT-5X3 package, it is ideal for space-constrained designs.

Detailed Technical Specifications

Key Features

• Bidirectional voltage translation without direction control
• Wide supply voltage range: 1.2V to 5.5V
• High data rate: up to 100 Mbps
• Low quiescent current: < 1 µA
• Small SOT-5X3 package for space-saving
• ESD protection up to ±8 kV HBM

Target Applications

• 5G base station control interfaces (e.g., translating 1.8V FPGA to 3.3V RF controller)
• Automotive dashboard display modules (e.g., connecting 1.2V MCU to 3.3V display driver)
• Industrial sensor networks (e.g., translating 3.3V sensor to 5V PLC input)
• Portable electronics (e.g., battery-powered devices with mixed voltage domains)
• IoT gateways (e.g., interfacing 1.8V SoC with 3.3V Wi-Fi module)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TXB0101DRLR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
